The ZKTeco X100 and X101 are standalone fingerprint access control terminals designed for doors that need fingerprint, RFID card and PIN verification in a compact IP66-rated unit. They are suitable for indoor and outdoor access points where simple local user management and flexible Wiegand integration are required.
The ZKTeco X100 and X101 are standalone fingerprint access control terminals designed for practical door security without relying on complex software. They support fingerprint verification, RFID card access and PIN code entry, giving businesses a compact and flexible way to manage authorised entry.
Both models are IP66 rated for water and dust protection, making them suitable for a wide range of indoor and outdoor access control applications where a clean, wall-mounted terminal is preferred.
Supports fingerprint, RFID card and PIN code verification, allowing different users to authenticate in the way that best suits the site.
Wiegand input/output allows the terminal to operate as a primary controller or as a secondary reader connected to an existing access control system.
The waterproof and dustproof housing makes the X100 and X101 suitable for exposed or semi-exposed access points.
The X100 and X101 can be used in different ways depending on the access control design. In primary control mode, they can manage entry and exit verification using Wiegand input. In secondary reader mode, they can send credential data through Wiegand output to an existing controller.
These terminals are well suited to sites that need a compact access point with biometric verification and simple local management. They are especially useful for smaller doors, staff entrances, storerooms, workshops and outdoor access points where fingerprint, RFID and PIN access are preferred over key-based entry.
The X100 and X101 share the same core access control capability, authentication methods and IP66 protection rating. The main difference is the physical form factor: the X100 is a slimmer vertical unit, while the X101 is a wider compact unit. This allows installers to choose the model that best fits the mounting location and preferred appearance.
| Specification | Details |
|---|---|
| Model | X100 / X101 |
| Product Type | Fingerprint Standalone Access Control Terminal |
| Display | N/A |
| Authentication Methods | Fingerprint / RFID Card / PIN Code via Physical Touch Keypad |
| User Capacity | 10,500 Users |
| Card Capacity | 10,000 Cards |
| Fingerprint Template Capacity | 500 Templates |
| Transaction Capacity | N/A |
| Password Length | 4 to 10 Digits (Factory Default: 4 Digits) |
| Fingerprint Verification Speed | < 0.3 Seconds |
| False Acceptance Rate | FAR ≤ 0.0001% |
| False Rejection Rate | FRR ≤ 0.01% |
| Card Type | 125kHz ID Card Standard / 13.56MHz IC Card Optional |
| Communication | Wiegand 26–44 Bits Input / Output × 1 |
| Access Control Interfaces | Electric Lock × 1, Door Sensor × 1, Exit Button × 1, Doorbell × 1 |
| Standard Functions | Access Control, Buzzer, Multiple Verification Methods, LED Status Indicators |
| LED Status Indicators | Orange: Programming / Green: Verification Successful / Red: Standby or Verification Failed |
| Error Feedback | Verification Fail: 3 Beeps / Operation Error: 3 Beeps, No Indicator |
| Power Supply | DC 12V 0.15A |
| Operating Temperature | -25°C to 60°C |
| Operating Humidity | 10% to 90% RH (Non-condensing) |
| Dimensions | X100: 140 × 45 × 15 mm / X101: 115 × 70 × 15 mm |
| Net Weight | X100: 0.105kg / X101: 0.140kg |
| Gross Weight | X100: 0.21kg / X101: 0.23kg |
| Supported Software | N/A |
| Installation | Wall Mount |
| Housing Material | ABS |
| Ingress Protection Rating | IP66 Waterproof and Dustproof |
| Certifications | ISO14001, ISO9001, CE, RoHS |
| Typical Applications | Small Business Doors, Staff Entrances, Outdoor Access Points, Standalone Door Access Control |
