ZKTeco Atlas Prox Series: State-of-the-Art Access Control Panels with Built-in Web Application

Discontinued: The Atlas Prox Series is no longer recommended for new installations. The current replacement is the Atlas Bio Series. This page remains for reference and ongoing support.

The Atlas Prox Series is a 1, 2 or 4-door RFID access control panel with a built-in web application. Three models (Atlas-100, Atlas-200, Atlas-400) cover one to four doors, with up to 5,000 users per panel and 10,000 transaction events stored on board.

Built-in web application, no software install
5,000 user capacity per panel
TCP/IP, Wi-Fi, OSDP and Wiegand

Downloads

Description

Discontinued product: The Atlas Prox Series is no longer recommended for new installations. The current replacement is the Atlas Bio Series. This page is retained for existing site reference, ordering of spares, and ongoing support.

The Atlas Prox Series is a multi-door RFID access control panel range with the management software built into the panel itself. Configure users, doors, schedules and reports through a browser – no separate software install required.

Three models

Atlas-100: 1 door, 2 Wiegand or OSDP readers, 3 inputs, 2 outputs.
Atlas-200: 2 doors, 4 Wiegand or OSDP readers, 5 inputs, 3 outputs.
Atlas-400: 4 doors, 4 Wiegand or 8 OSDP readers, 9 inputs, 5 outputs.

Built-in web application

Configuration runs from a browser (Chrome, Firefox or Edge). Features include user enrolment and management, door control and monitoring, lockdown, reporting, maps, anti-passback, first-card opening, multi-card opening, card design and duress PINs. A mobile app adds remote unlock, lockdown and recovery, event and alarm access, and user management on the go.

Key Features

5,000 users per panel: 10,000 transaction event database plus unlimited archive downloads.
Communication: TCP/IP and Wi-Fi for network connectivity. RS485 for Wiegand and OSDP readers at 9600 bps.
Reader compatibility: ZKTeco KR Series readers and third-party 125 kHz and 13.56 MHz Wiegand, OSDP and RS-485 readers.
Output relays: 3 Form-C SPDT relays, 5A at 36V DC or 8A at 30V AC.
Power: 12V DC 3A supply (included). Power over Ethernet (PoE) supported. 9W draw at 12V DC 750mA.
Scalable: One Primary panel supports up to 20 Secondary panels. Maximum 84 doors across all 21 panels.

What is in the bundle

Included: Atlas Prox control panel, metal case, 12V DC 3A power supply, FR107 diode for each lock, 2 keys for the metal case.
Operating environment: 0 to 45C, 20 to 80 per cent humidity.
Bundle dimensions: 380 x 80 x 280 mm (L x W x H). Wall-mount in a powder-coated aluminium enclosure.
Secure browser access: SSL/TLS over wired or wireless TCP/IP.

Specifications
