The ZKTeco QR500 is a combined QR code and 13.56 MHz Mifare reader for doors that need to accept phone-based credentials alongside cards. Wiegand, RS485 and USB outputs make it a clean fit for visitor management, ticketed entry, gym phone passes and contractor sign-in. Reads QR, PDF417 and Data Matrix from both printed badges and phone screens.
The QR500 is the reader buyers spec when the site has moved (or is moving) to phone-based credentials but still needs to support Mifare cards for staff. It earns its place at the door by reading QR codes off a phone screen reliably, including dimmed screens and protective glass.
| Feature | Specification |
|---|---|
| International Standard | ISO / IEC 14443A RS485 Protocol |
| 1D Barcode | CODABAR, CODE 128, CODE 39, CODE 93, Data Matrix, EAN128, GS1 Databar, PDF417, QR, UPC/EAN |
| RFID | DESFire EV1, Mifare Ultralight, Ntag, S50 / S70 |
| Operating Frequency | 13.56MHz |
| Power | DC 12V (±5%), USB 5V |
| Operating Distance | QR≥5cm, RFID Card ≥ 4cm |
| Communication | RS485, USB, Wiegand |
| Operating Temperature | -10℃ ~ 50℃ |
| Storage Temperature | -20℃ ~ 80℃ |
| Operating Humidity | 20% - 80% |
| Dimensions | 86*86*50mm |
| USB Cable | 1000mm |
