ZKTeco G5: The Ultimate Outdoor Multi-Biometric Access Control Terminal

ZKTeco G5

A multi-biometric access control terminal designed for outdoor use. It supports various biometrics authentication methods, including facial recognition, fingerprint verification, multi-tech cards detection and password. The device features an 8 inch TFT color touch screen with narrow bezel design and has an IP66 waterproof & dustproof and IK04 vandal proof protection level.

The ZKTeco G5 runs on Android 9.0 and has a 64bit Eight Core Customized Computer Vision CPU. It also has 2GB LPDDR3 and 16GB eMMC storage. The device supports TCP/IP, Wi-Fi, Bluetooth and USB communication.

The ZKTeco G5 has a 2MP binocular camera and can read dynamic QR codes on the ZKBioSecurity mobile application. It also supports QR code, PDF417, Data Matrix, MicroPDF417 and Aztec scanning in third-party development projects. The device can read dual-frequency (125kHz and 13.56MHz) cards as standard and has an optional multi-tech card module.

The ZKTeco G5 has a protective level of IP66 without a Fingerprint/QR Code Reader and IP65 with a Fingerprint/QR Code Reader. It also has an IK04 rating. The card reading distance is between 1cm and 5cm. The face-camera distance range is between 0.3m to 3.0m (Human height: 0.9m to 2.4m). Face recognition time is less than 1s and face verification accuracy is greater than or equal to 99%. The device can also support an optional optical fingerprint sensor.

The ZKTeco G5 can store up to 100,000 users, 100,000 face templates, 30,000 fingerprints (optional) and 100,000 cards. It can also store up to 5 million records. The device supports push, schedule bell, automatic status switch, record query, access levels, groups, holidays, DST, duress mode (password & fingerprint), anti-passback, customization of wallpaper & screen saver and tamper alarm.

Features

  • Multi-biometric access control terminal designed for outdoor use
  • Supports various biometrics authentication methods, including facial recognition, fingerprint verification, multi-tech cards detection and password
  • Features an 8 inch TFT color touch screen with narrow bezel design and has an IP66 waterproof & dustproof and IK04 vandal proof protection level
  • Runs on Android 9.0 and has a 64bit Eight Core Customized Computer Vision CPU with 2GB LPDDR3 and 16GB eMMC storage
  • Supports TCP/IP, Wi-Fi, Bluetooth and USB communication

Product Details

The ZKTeco G5 is a state-of-the-art multi-biometric access control terminal designed for outdoor use. It supports various biometrics authentication methods such as facial recognition, fingerprint verification, multi-tech cards detection and password.

The device features an 8 inch TFT color touch screen with narrow bezel design that provides a clear display of information. Additionally, the ZKTeco G5 has an IP66 waterproof & dustproof rating as well as an IK04 vandal proof protection level that ensures its durability in outdoor environments.

The ZKTeco G5 runs on Android 9.0 operating system and is powered by a 64bit Eight Core Customized Computer Vision CPU that provides fast processing speeds for smooth operation. It also has ample storage with its 2GB LPDDR3 memory and 16GB eMMC storage.

The device supports various communication methods such as TCP/IP for wired network connections, Wi-Fi for wireless connections and Bluetooth for short-range wireless communication with other devices. It also has USB ports for data transfer or connecting external devices.

The ZKTeco G5 is equipped with a high-resolution 2MP binocular camera that captures clear images for facial recognition. It can also read dynamic QR codes on the ZKBioSecurity mobile application for easy access control management. Additionally, it supports QR code scanning as well as other barcode formats such as PDF417, Data Matrix, MicroPDF417 and Aztec in third-party development projects.

The device can read dual-frequency (125kHz and 13.56MHz) cards as standard for access control management using RFID technology. It also has an optional multi-tech card module that supports various card formats such as ISO14443A/B & ISO15693 & HID Prox.

The ZKTeco G5 has a high protective level with its IP66 rating without a Fingerprint/QR Code Reader and IP65 rating with a Fingerprint/QR Code Reader installed. It also has an IK04 rating that protects it against external impacts.

The card reading distance of the ZKTeco G5 is between 1cm and 5cm which provides convenient access control management without the need for physical contact with the device. The face-camera distance range is between 0.3m to 3.0m (Human height: 0.9m to 2.4m) which allows for easy facial recognition even at a distance.

The face recognition time of the ZKTeco G5 is less than 1s which provides fast and efficient access control management. The face verification accuracy is greater than or equal to 99% which ensures high security and reliability. The device can also support an optional optical fingerprint sensor for additional biometric authentication methods.

The ZKTeco G5 can store up to 100,000 users, 100,000 face templates, 30,000 fingerprints (optional) and 100,000 cards. It can also store up to 5 million records for easy access control management and tracking.

The device supports various firmware functions such as push for real-time data synchronization, schedule bell for setting alarms or reminders, automatic status switch for changing the device status based on predefined conditions, record query for searching and viewing access control records, access levels for setting different levels of access control, groups for managing users in groups, holidays for setting holiday schedules, DST for daylight saving time adjustments, duress mode (password & fingerprint) for emergency situations, anti-passback for preventing unauthorized entry or exit, customization of wallpaper & screen saver for personalizing the device display and tamper alarm for detecting unauthorized tampering with the device.

Specifications

PropertyValue
SYSTEM
Operation SystemAndroid 9.0
CPU64bit Eight Core Customized Computer Vision CPU
Storage2GB LPDDR3 16GB eMMC
SDKAndroidL CDP, PUSH SDK
BASIC
CommunicationTCP / IP, Wi-Fi, Bluetooth, USB
Display8 inch TFT LCD Color Screen
Screen TypeCapacitive Touch Screen
Resolution800*1280
Camera2MP Binocular Camera
QR Code (optional)Dynamic QR codes on the ZKBioSecurity mobile application QR code, PDF417, Data Matrix, MicroPDF417, Aztec scanning in third-party development projects
Card TypeDual-frequency (125kHz and 13.56MHz)
card module (standard)
Multi-tech Card Module (optional)
ISO14443A/B & ISO15693 & HID Prox
INTERFACE
USB1 USB 3.0, 1 USB 2.0, 1 Micro USB
Power Adapter12V 3A
EthernetRJ45, 1000M
RS2321
RS4851
Wiegand1 input, 1 output
Auxiliary input1
Sensor1
Exit Button1
Lock1
Alarm1
Bell1
Power out1, 12V
Reset Button1
PERFORMANCE
Protective levelIP66 without Fingerprint / QR Code Reader;
IP65 with Fingerprint / QR Code Reader;
IK04
Card Reading Distance1cm – 5cm
Face RecognitionFace-camera distance
Range0.3 m to 3.0 m; (Human height: 0.9 m to 2.4 m)
Face Recognition Time< 1s
Face Verification Accuracy≥99%
Fingerprint Sensor Type (optional)Optical
Fingerprint Comparison Time≤0.5s
Facial Recognition Method1:1, 1:N
Fingerprint Verification Method1:1, 1:N
Facial Recognition AlgorithmZKFace 5.6.2
Fingerprint Recognition AlgorithmZKFinger 10.0
FIRMWARE
User Capacity100,000
Face Templates Capacity100,000
Fingerprint Capacity (optional)30,000
Card Capacity100,000
Record Capacity5,000,000
Standard Firmware FunctionsPush, Schedule Bell, Automatic Status Switch, Record Query, Access Levels, Groups, Holidays, DST, Duress Mode (Password & Fingerprint), Anti-Passback, Customization of Wallpaper & Screen Saver, Tamper Alarm
LanguageEnglish, Korean, Latin American, Indonesian, Vietnamese, traditional Chinese, Portuguese, Spanish, Farsi, Japanese, Russian and Thai
SoftwareZKBio Time, ZKBioSecurity, ZKBioCV Security
BODY TEMPERATURE DETECTION(OPTIONAL)
Preventative MeasuresMask detection / Body temperature detection
Temperature Measurement Distance50cm to 120cm (1.64ft to 3.94ft)
Temperature Measurement Accuracy±0.3°C (±0.56°F)
Temperature Measurement Range20°C to 50°C (68°F to 122°F)
GENERAL
Power Supply12V 3A; PoE (IEEE802.3af/at)
Dimensions279.5mm*141mm*29mm (11in*5.55in*1.14in)
Operating Temperature-10℃ to 50℃ (14°F to 122°F)
Operating Humidity<90% RH
Operating EnvironmentOutdoor
Gross Weight1.2 kg
Installation MethodWall-mounted or Turnstile top-mount bracket
CertificationsCE, FCC, ISO9001, ISO14001, IP66, IK04
