7″ PoE touchscreen indoor monitor with SIP video intercom, Wi-Fi, alarm integration, and IP camera support.
The ZKTeco VT07-B26L-W is a high-tech indoor monitor that combines video intercom, alarm integration, and smart home communication into one sleek unit. Designed for easy installation and flexible deployment, it features a bright 7-inch touchscreen, dual Ethernet ports, and support for both PoE and Wi-Fi networks.
The VT07-B26L-W is the perfect all-in-one indoor screen for secure communication, real-time monitoring, and smart alarm management.
| System | Linux |
|---|---|
| RAM | 128 MB |
| ROM | 128 MB |
| Front Panel | Plastic |
| Power Supply | PoE (802.3af ) or DC 12V/2A |
| Standby Power | 2 W |
| Rated Power | 9 W |
| Ethernet Ports | 2 x RJ45, 10 / 100 Mbps self-adaptive |
| Support Wi-Fi | IEEE 802.11 b / g / n, @ 2.4 GHz |
| TF card slot | 1 (max. 32GB) |
| RS485 | 1 |
| Power Output | 1 (12V/100mA) |
| Doorbell Input | Max. 8 input |
| Alarm Input | Support 8 sensor zones: smoke, gas, PIR, door, window, panic and flood |
| Installation Method | Wall mount (on flat surface) |
| Dimensions (H*W*D) | 195 x 130 x 14.5 mm |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Display | |
| Display | 7-inch TFT LCD |
| Screen | Capacitive touch screen |
| Resolution | 1024 x 600 |
| Audio | |
| Audio Codec | G.711 |
| Echo Cancellation | Support |
| DTMF | RFC2833 |
| Microphone | Built-in microphone |
| Speaker | 8Ω / 1W |
| Video | |
| Video Codec | H.264 |
| Networking | |
| Protocol | SIP 2.0, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPV4, ARP, ICMP |
