ZKTeco UHF5 & UHF10 Pro: Third-Generation UHF Readers

ZKTeco UHF5 Pro & UHF10 Pro: High-Performance Long-Range UHF Readers

The ZKTeco UHF5 Pro and UHF10 Pro are third-generation UHF readers designed for vehicle and personnel management. With extended reading distances, advanced communication interfaces, and robust designs, they provide reliable access control solutions for a variety of environments.

Description

ZKTeco UHF5 Pro & UHF10 Pro: Advanced Long-Range UHF Readers for Vehicle & Personnel Management

The ZKTeco UHF5 Pro and UHF10 Pro are third-generation Ultra High Frequency (UHF) readers developed for enhancing vehicle and personnel management systems. These devices feature dual working modes, “Trigger to Read” and “Always Read,” providing flexibility based on specific operational needs. Their extended reading range and robust IP66-rated design make them suitable for both indoor and outdoor installations, providing reliable access control in various environments, including gated communities, parking lots, and large campuses.

The UHF5 Pro and UHF10 Pro offer Wiegand and RS485 communication options, ensuring seamless integration with existing systems. They are equipped with a 7-color LED indicator at the bottom, which provides clear visual feedback on reading status, enhancing the overall user experience. The UHF5 Pro has a reading distance of up to 8 meters, while the UHF10 Pro can read up to 20 meters, making these readers ideal for large-scale applications that require high-performance UHF technology.

Key Features

  • Extended Reading Range – UHF5 Pro reads up to 8 meters; UHF10 Pro reads up to 20 meters, providing high-performance long-range identification.
  • Dual Working Modes – Supports “Trigger to Read” and “Always Read” modes, offering operational flexibility.
  • Multiple Communication Interfaces – Provides Wiegand and RS485 communication options for easy system integration.
  • IP66-Rated Design – Built to withstand harsh environmental conditions, ensuring durability and reliability in outdoor installations.
  • Visual Feedback – Equipped with a 7-color LED indicator for easy identification of reading status.

Technical Specifications

  • Reading Distance: UHF5 Pro: Up to 8 meters; UHF10 Pro: Up to 20 meters
  • Antenna Gain: UHF5 Pro: 9 dBi; UHF10 Pro: 12 dBi
  • Communication: Wiegand, RS485
  • Ingress Protection: IP66
  • Operating Voltage: DC 9V to 15V
  • Operating Temperature: -20°C to 65°C
  • Frequency Range: 865 MHz to 868 MHz (Region E) and 902 MHz to 906 MHz (Region F)
  • Dimensions: UHF5 Pro: 308.5 × 308.5 × 67.5 mm; UHF10 Pro: 445 × 445 × 67.5 mm

Applications

The ZKTeco UHF5 Pro and UHF10 Pro are suitable for various applications that require efficient long-range identification, including vehicle management in parking lots, access control in gated communities, and personnel management in large campuses and secure facilities. Their extended reading ranges and robust construction make them ideal for both indoor and outdoor installations, ensuring reliable performance in all environmental conditions.

Why Choose ZKTeco UHF5 Pro & UHF10 Pro?

  • Extended Range & High Performance – Offers long-range identification for vehicle and personnel management, ensuring quick and efficient access control.
  • Built to Last – IP66-rated design ensures durability and reliability, suitable for both indoor and outdoor environments.
  • Flexible Working Modes – Supports “Trigger to Read” and “Always Read” modes, providing operational flexibility to meet specific needs.

Specifications

ModelUHF5E Pro & UHF5F ProUHF10E Pro & UHF10F Pro
Reading Distance2 to 8 meters (Hand held test)10 to 20 meters (Hand-held test)
(Actual scenario test is around 4m)(Actual scenario test is around 8m)
Antenna Gain9 dBi12 dBi
Dimensions (mm)308.5 * 308.5 * 67.5445 * 445 * 67.5
Weight1.8kg3kg
Power1.2 – 4.2W1.2 – 4.5W
FrequencyE: 865MHz - 868MHz
F: 902MHz - 906MHz (adjustable)
Communication InterfaceWiegand; RS485; USB configuration parameters (Wiegand, RS485 requires one of two options)
Interface ProtocolEPC global UHF Class 1 Gen 2 / ISO 18000-6C
Working ModeRead Always (Default) and Read by Trigger
Output Power19dBm - 30dBm
Protection LevelIP66
Working VoltageDC 9-15V
Working Temperature and Humidity-20°C - 65°C; <85%
Storage Temperature and Humidity-20°C - 80°C; <85%
RS485 CommunicationOptional baud rate (9600, 19200, 38400, 57600, 115200); the default is 115200
