ZKTeco X628-C: Fingerprint Time Attendance Terminal with Touch Screen

ZKTeco X628-C

A time attendance terminal with a built-in fingerprint reader and a 3-inch touch screen. It has been upgraded with new firmware that provides an unprecedented user experience.

Features

  • Supports fingerprint identification
  • Stores up to 3,000 fingerprint templates
  • Supports ID card identification (optional)
  • Supports RS232/485 and TCP/IP communication
  • User-friendly management software for easy configuration and attendance reporting

Product Details

The ZKTeco X628-C is a time attendance terminal that features a built-in fingerprint reader and a 3-inch touch screen. It has been upgraded with new firmware that provides an unprecedented user experience, including a stunning GUI, rock-solid stability, faster matching speed, and better expandability. Users can easily manage data by networking the X628-C via RS232/485, TCP/IP, and USB-host. All functions can still operate in a networking state.

The X628-C has a fingerprint capacity of 3,000 and an ID card capacity of 10,000 (optional). It has a record capacity of 100,000. Its standard functions include Workcode, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch, Webserver, External Printer, 5 digit user ID, and Multiple Verify Mode. Optional functions include ID/Mifare/HID, Photo ID, ADMS, Webserver, External Bell and Printer.

The X628-C uses ZKTime.Net 3.0 software and has a power supply of DC 5V 0.8A. Its verification speed is ≤1 Sec. The device operates at a temperature range of 0 °C- 45 °C.

Specifications

FeatureSpecification
Fingerprint Capacity3,000
ID Card Capacity10,000 (Optional)
Record Capacity100,000
Display3-inch Screen
CommunicationRS232/485, TCP/IP,USB-host
Standard FunctionsWorkcode, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch, Webserver, External Printer, 5 digit user ID, Multiple Verify Mode
Optional FunctionsID/Mifare/HID, Photo ID, ADMS, Webserver, External Bell and Printer
SoftwareZKTime. Net 3.0
Power SupplyDC 5V 0.8A
Verification Speed≤ 1 Sec.
Operating Temp.0 °C- 45 °C
Operating Humidity20%-80%
Dimension190 × 135.8 × 51.5mm (Length × Width × Thickness)
Net Weight0.9 kg
