ZKTeco FBL4200 Pro: Durable Flap Barrier Turnstile with RFID and Fingerprint Authentication
ZKTeco FBL4200 Pro
The ZKTeco FBL4200 Pro is a durable flap barrier turnstile designed for smooth and silent operation. It works with RFID and fingerprint authentication, allowing for maximum throughput of 30 and 25 people per minute respectively. The turnstile is made of stainless steel and acrylic, making it ideal for indoor and outdoor use.
The FBL4200 Pro has several parameters including power requirements of AC 100V to 120V or 200V to 240V at 50/60Hz, working temperature range of -28°C to 60°C, working humidity range of 5% to 80% (non-condensing), working environment of indoor/outdoor (if sheltered), speed of throughput with RFID at maximum 30/minute and fingerprint at maximum 25/minute.
Features
- Works with RFID and fingerprint authentication
- Maximum throughput of 30 people per minute with RFID
- Maximum throughput of 25 people per minute with fingerprint
- Made of stainless steel and acrylic
- Ideal for indoor and outdoor use
Product Details
The ZKTeco FBL4200 Pro is a Flap Barrier Turnstile for additional Lane series designed for smooth and silent operation and draws very little power. It’s made of stainless steel which makes FBL4200 highly durable. The FBL4200 Pro is a sleek and durable flap barrier turnstile that works with RFID and fingerprint authentication, allowing for maximum 30 and 25 people per minute throughput respectively.
The turnstile is made of stainless steel and acrylic, making it ideal for indoor and outdoor use. It has several parameters including power requirements of AC 100V to 120V or 200V to 240V at 50/60Hz, working temperature range of -28°C to 60°C, working humidity range of 5% to 80% (non-condensing), working environment of indoor/outdoor (if sheltered), speed of throughput with RFID at maximum 30/minute and fingerprint at maximum 25/minute, lane width of 600mm, footprint of 1350mm by 840mm, dimensions of 1350mm by 300mm by 1010mm, net weight of 72kg, LED indicator support, SUS304 stainless steel cabinet material and lid material, acrylic barrier material (optional: tempered glass), barrier movement retracting, emergency mode support, medium security level, MCBF of 2 million.
Specifications
| Feature | Specification |
|---|---|
| Power Requirements | AC 100-120V/200-240V, 50/60Hz |
| Working Temperature | -28°C to 60°C |
| Working Humidity | 5% to 80% |
| Working Environment | Indoor/outdoor (if sheltered) |
| Speed of Throughput | RFID: Maximum 30/minute Fingerprint: Maximum 25/minute |
| Lane Width (mm) | 600 |
| Footprint (mm*mm) | 1200*870 |
| Dimension (LWH) | 8703001000 (mm) |
| Dimension with Packing (LWH) | 8703001000 (mm) |
| Net Weight (kg) | 97 |
| Weight with Packing (kg) | 144 |
| LED Indicator | Supports |
| Cabinet Material | SUS304 Stainless Steel |
| Lid Material | SUS304 Stainless Steel |
| Barrier Material | Acrylic (optional: tempered glass) |
| Barrier Movement | Retracting |
| Emergency Mode | Supports |
| Security Level | Medium |
| MCBF | 2 million |
| Warranty | 1 year |
