The ZKTeco ProID Series is a family of card readers that offer flexible technology options and robust all-weather protection for indoor or outdoor applications.
The ZKTeco ProID Series is a family of card readers designed to offer card technology options to customers such as 125KHz EM, 13.56MHz IC, DESFire, FeliCa or Legic. With a robust all-weather protection and a beautiful modern design, the ProID family is the best choice for indoor or outdoor applications.
The ProID Series has a range of models with different features and capabilities. For example, the ProID10 model has a read range of 3.5cm for EM/IC cards, while the ProID20/30/40 models have a read range of 5cm for EM/IC cards. The reading time for all models is ≤300ms.
The ProID Series also has an external LED control and external buzzer control input port, and is made of ABS+PC material. The output format can be adjusted to Wiegand 26bit or 34bit, and the operating voltage is 7~13V DC. The current draw is <80mA, and the LED indicator has a pulsing white standby light with red and green LEDs.
Overall, the ZKTeco ProID Series offers advanced features, flexible connectivity, and a robust design, making it a reliable and secure card reader for businesses and organizations seeking an access control solution.
| Feature | Specification |
|---|---|
| Read Range | ProID10 EM / IC: 3.5cm |
| ProID20 / 30 / 40 EM / IC: 5cm | |
| Reading Time | ≤ 300ms |
| Input Port | External LED Control / External Buzzer Control |
| Material | ABS + PC |
| Output Format | Wiegand 26bit or 34bit Adjustable |
| Operating Voltage | 7 ~ 13V DC |
| Current Draw | < 80mA |
| LED | Pulsing White Standby Light / Red and Green LEDs |
| Operating Temperature | -20 °C ~ 65 °C |
| Operating Humidity | 10% ~ 90% Relative Humidity Non-Condensing |
| Audio | Beep |
| Ingress Protection Rating | IP65 |
| Dimension | ProID10: 80.5 × 44 ×15mm |
| ProID20 / 30: 90 × 90 × 16mm | |
| ProID40: 116 × 75 × 15mm |
