Armatura OmniAC30 Multi-Biometric Terminal – Face, Palm, RFID & QR Access Control

Armatura OmniAC30 IP66 Biometric Terminal with Face, Palm, RFID & QR Access
Armatura OmniAC30 IP66 Biometric Terminal with Face, Palm, RFID & QR Access
Armatura OmniAC30 IP66 Biometric Terminal with Face, Palm, RFID & QR Access
Armatura OmniAC30 IP66 Biometric Terminal with Face, Palm, RFID & QR Access

Armatura OmniAC30 – All-Weather Biometric Terminal

5″ touchscreen terminal with palm, face, RFID & QR code authentication. IP66-rated for versatile indoor/outdoor access control.

  • Enquire Now
  • Trade Welcome
Categories: , Tags: , , , , , , , , Brand:

Description

Overview

The Armatura OmniAC30 is a high-performance, all-weather biometric terminal combining facial recognition, palm authentication, RFID card reading, and QR code scanning in a sleek, IP66-rated enclosure. With a large 5-inch touchscreen, PoE support, and flexible mounting options, it’s designed for both outdoor and indoor deployments.

Authentication Options

  • Face recognition (up to 100,000 users)
  • Palm recognition (up to 100,000 users)
  • RFID cards (125KHz / 13.56MHz – MIFARE, iCLASS, FeliCa, etc.)
  • BLE mobile credentials (Armatura ID app)
  • QR code and PIN code

Key Features

  • IP66 weatherproof, -15°C to 55°C operating range
  • 5” HD touchscreen (720×1280) with intuitive UI
  • Advanced dual-camera system with anti-spoofing liveness detection
  • Mounts to single gang, European, or Asian backboxes
  • Compatible with ZKTeco/Armatura access systems and SIP intercoms
  • BioCode support – secure biometric QR codes for mobile

Technical Specifications

  • Processor: Quad-core 1.2GHz + 2.4 TOPs NPU
  • Memory: 1GB RAM + 8GB Flash (or 2GB + 16GB depending on model)
  • Power: 12V–24V DC or PoE (802.3at)
  • Connectivity: TCP/IP, RS-485 (OSDP V2.0/2.2), Wiegand, SIP
  • Outputs: Lock, alarm, auxiliary
  • Dimensions: 209 × 97 × 28.5 mm

Authentication Performance

  • Face: 100ms, 1:N or 1:1, 400–1400mm range
  • Palm: 140ms, 1:N or 1:1, 180–400mm range
  • QR Code Scan: 12–52mm scan range
  • RFID: Read range up to 50mm

Applications

  • Government facilities & secure entrances
  • Commercial buildings & corporate HQs
  • Healthcare & research facilities
  • Universities, banks, and retail access points

OmniAC30 provides future-ready security with touchless biometrics, mobile integration, and intercom capabilities — all housed in a slim, elegant, and durable design.

Specifications

OmniAC30 Technical Specifications
FeatureSpecification
Authentication MethodsFace, Palm, QR Code, RFID, PIN
Face Capacity50,000 (1:N) / 100,000 (1:1); Optional: 100,000 (1:N)
Palm Capacity5,000 (1:N) / 100,000 (1:1)
Card Capacity100,000 RFID cards
Display5.0″ TFT LCD Touchscreen, 720×1280 resolution
CameraDual IR & Visible Light, 720×1280 output
Verification Speed<100ms (Face), <140ms (Palm)
Face Authentication Distance400mm – 1400mm
Palm Authentication Distance180mm – 400mm
ConnectivityTCP/IP, RS-485, Wiegand In/Out, OSDP 2.0/2.2
Network SecurityTLS 1.2, AES-128, Secure OSDP Channel
Power Input12V-24V DC, Max 10W / PoE (IEEE802.3at, Max 12W)
Operating Temperature-15°C to 55°C
Protection RatingIP66 Water & Dustproof
Video IntercomSIP V2.0, 2-way Audio, Armatura ICS App Support
Dimensions97 × 28.5 × 209 mm
MountingSingle Gang / European / Asian Box; Speed Gate Option
CertificationsCE, FCC, RoHS, ISO/IEC 19795-2

Downloads

OmniAC30 all weather outdoor multi tech smart standalone terminal A&E Specifications Version 1.2 20240829
OmniAC30 Datasheet 20250318
ARMATURA OmniAC30 QSG EN v2.3 20250120
Armatura ID User Manual EN v1.3
ARMATURA OmniAC30 IG EN v1.5 20250120
ARMATURA OmniAC30 UM EN v2.3 20250124
Armatura Access Hardware Functions Selection Guide 20240711
Armatura CONNECT User Manual EN v1.3 20221031
